Highland Stainless Steel Backplate


The Highland Stainless Steel Backplate is made from 11-gauge (.115 in / 3 mm), 304 stainless steel and weighs in at approximately 5 lbs (2.3 kg).

SKU: HL801 Category: Tags: ,


Stainless Steel Backplate

  • 11-gauge (.115 in / 3 mm), 304 stainless steel
  • Weighs approx. 5 lbs (2.3 kg) and the aluminum weighs 1.7 lbs (770 g)
  • All edges are beveled to protect the harness
  • The 3 holes at the top of the plate offer variable height adjustment for air cell and cylinder mounting. In addition, a corresponding lower oval slot allows for lower band bolts that may be misaligned
  • Slots at bottom for use with 1” or 2” crotch strap
  • 3/8” accessory mounting holes along the sides and bottom
  • There are 4 upper and lower slots to accommodate nylon cylinder bands so a single cylinder can be strapped directly to the plate. Having 4 slots provides stability and prevents cylinder “swinging”
  • Hardware not included

Additional information


Stainless Steel, Aluminium

Steel Plate

304 stainless

Aluminum Plate

6061 anodized

Weight (steel)

Approx 5 lbs (2.2 kg)

Weight (aluminum)

1 lb 11 oz (753 g)


Electro-plate for both
